Steel
Composition & Properties:
Low carbon steel cable trays are manufactured from high-quality mild steel with carbon content typically below 0.25%,
offering excellent structural integrity and cost-effectiveness.
Key Features:
– High Load Capacity: Superior strength-to-weight ratio, capable of supporting heavy cable loads
– Economic Solution: Most cost-effective option for standard indoor applications
– Easy Fabrication: Excellent weldability and formability for
custom configurations
– Surface Treatment Options: Available with galvanized, powdercoated, or painted finishes for enhanced protection
– Wide Temperature Range: Maintains structural integrity across standard operating temperatures
▪ Stainless Steel
Composition & Properties:
Manufactured from premium grades including 304 and 316 stainless steel, providing exceptional corrosion resistance and
longevity in demanding environments.
Key Features:
– Superior Corrosion Resistance: Excellent performance in harsh, corrosive environments
– Hygienic Properties: Non-porous surface ideal for clean room and food processing applications
– High Temperature Tolerance: Maintains strength and appearance at elevated temperatures
– Low Maintenance: Self-passivating surface requires minimal upkeep
– Aesthetic Appeal: Professional appearance suitable for exposed installations
– Chemical Resistance: Outstanding resistance to acids,alkalis, and organic compounds
▪ Aluminum
Composition & Properties:
Precision-engineered from high-grade aluminum alloys (typically 6061-T6 or 6063-T5), combining lightweight construction with
excellent structural performance.
Key Features:
– Lightweight Design: Approximately 65% lighter than steel,reducing installation costs and structural load
– Natural Corrosion Resistance: Forms protective oxide layer preventing further oxidation
– Excellent Conductivity: Superior electrical and thermal conductivity properties
– Non-Magnetic: Ideal for sensitive electronic environments
– Recyclable: Environmentally sustainable with high recycling value
– Dimensional Stability: Minimal thermal expansion and contraction – Easy Installation: Reduced weight simplifies handling and installation procedures
